Print Inspection System

Print Inspection System

Engineered Vision’s print inspection system, which is a method of factory automation, will give you the capability to automatically inspection every single product through machine vision. There are unlimited print measurement applications across all industries, and a custom print system will be designed to meet your unique application.

Machine vision uses a camera and a computer intelligent of examining images in real time to produce the needed machine feedback to create smart in-process determinations. Various measurements can be taken concurrently along with part tracking for proper placement. This machine vision system can substitute skip lot measurements and/or CMM with 100% inspection executed in-line.

What is Included in our typical package?

Vision Hardware

  • Camera, lens, & light
  • Camera PC and lifetime software license
  • Camera & light Controller
  • Human machine interface (HMI)
  • Corresponding std. mounting materials & std. cables


  • OCR/OCV – lifetime license
  • Customized printing inspection
  • Customized communication to PLC


  • Installation of vision hardware
  • Install communication cabling (digital I/O)
  • Camera and lighting adjustment
  • Commissioning support 8 hr

What is the Process?

Engineered Vision will design, procure, install, and support the machine vision system that meets your application needs through the following steps:

  1. We will start by providing a Free Consultation and site visit to identify potential camera, light, and trigger locations
  2. Next we perform free lab testing on the provided part samples with a skeleton vision program to ensure machine vision will work for your application
  3. We provide the results and generate a customized solution for your application. At this point we will know where your machine vision problem sits on the basic to complex spectrum.
  4. See typical vision package components listed above.
  5. nstallation – we will procure the machine vision components from our established distribution partners known to deliver superior quality products (typically > 20 years experience) and install them at your facility with minimal downtime.
  6. Support – commissioning and technical support is provided to ensure your new manufacturing improvements come headache free.

We also preform many different machine vision applications in addition to custom machine design and robotics integration. Want to learn more on how engineered Vision can help you?
